Understanding ballistic protection levels

Ballistic protection levels indicate which threats your armored vehicle will stop. American Armoring builds to international standards: CEN (Comité Européen de Normalisation), NIJ (National Institute of Justice), and STANAG (NATO standardization agreement). Every armor protection level we offer is independently tested against real ballistic threats – from handguns to armor-piercing rifles.

Your threat environment determines which bulletproof car level makes sense. Armor levels A1 to A3 handle standard handgun calibers: .38 Special, 9mm, and .357 Magnum. A4 through A6 armor ratings stop more serious threats – shotguns, high-powered handguns, and AK-47 rounds. A6 is what most civilian clients choose because it gives comprehensive armored vehicle protection without excessive weight. A7 through A9 address assault rifle threats like 5.56mm NATO and 7.62x51mm. The top bulletproof levels – A10 through A12 – defend against armor-piercing rounds and .50 BMG, which military contracts and heads of state require.

Most civilian clients choose protection levels between A4 and A9, as they cover real-world threats. Government agencies and security firms working in conflict zones need A12 and higher for armor-piercing rifle protection. Our ballistic table below shows weapon types matched to NIJ, CEN, STANAG, and UL protection standards.

Armoring
WeaponWeapon
LevelsLevels
ProjectileProjectile
No one protects you better.
Name
Caliber
Class
StanagStanag
ULUL
NijNij
CenCen
Weight±
Type
Velocity±
Compare
Weapon A1
.38 Special
9 x 29mmR
Revolver
-
1
A1
HG1
BR1
125 grains8.09 grams
FMJ
Full Metal Jacket
1,075 ft/s (328 m/s)
Bullet Level 1
Weapon A2
9mm Luger
9 x 19mm
Handgun
-
1
A2
HG1
BR2
124 grains15.55 grams
FMJ/RN
Full Metal Jacket / Round Nose
1,305 ft/s (398 m/s)
Bullet Level 2
Weapon A3
.357 Magnum
9 x 33mmR
Revolver
-
2
A3
HG1
BR3
158 grains10.23 grams
FMJ/JSP
Full Metal Jacket / Jacketed Soft Point
1,430 ft/s (436 m/s)
Bullet Level 3
Weapon A4
.44 Magnum
11 x 33mmR
Revolver
-
3
A4
HG2
BR4
240 grains15.55 grams
JHP
Jacketed Hollow Point
1,430 ft/s (436 m/s)
Bullet Level 4
Weapon AS
Shotgun
12 Gauge
Shotgun
-
4
ASG
HG2+
SG2
436 grains28.25 grams
Slug
1,650 ft/s (503 m/s)
Bullet Level 5
Weapon A5
300AAC BlackoutTokarev
7.62 x 35mm7.62 x 25mm
CarbineHandgun
I
5
A5
RF1
BR4+
84 grains5.50 grams125 grains9.10 grams
FMJLCSJ
Full Metal Jacket
2,185 ft/s (666 m/s)1,600 ft/s (488 m/s)
Bullet Level 6
Weapon A6
AK-47/Kalashnikov
7.62 x 39mm
Rifle
I
5
A6
RF1
BR5
120 grains7.77 grams
FMJ
Full Metal Jacket
2,380 ft/s (725 m/s)
Bullet Level 7
Weapon A7
M4/M16
5.56 x 45mm (M193)
Carbine
I
5
A7
RF1
BR5
56 grains3.63 grams
FMJ/BT
Full Metal Jacket / Boattail Bullet
3,210 ft/s (978 m/s)
Bullet Level 8
Weapon A8
M4/M16
5.56 x 45mm NATO(SS109)
Carbine
I
5
A8
RF1
BR5
62 grains4 grams
FMJ/BT
Full Metal Jacket / Boattail Bullet
3,110 ft/s (948 m/s)
Bullet Level 9
Weapon A9
Remington 700
.308 or 7.62 x 51mm(M80 Ball)
Rifle
I
8
A9
RF2
BR6+
149 grains9.65 grams
FMJ Ball
Full Metal Jacket
2,780 ft/s (847 m/s)
Bullet Level 10
Weapon A10
AK-47M4
7.62 x 39mm API BZ5.56 x 45mm GT AP (M855)
RifleCarbine
II
9
A10
RF2
BR7
122/62 grains7.90/4.02 grams
API/PB/HCGT/AP/BT
Armor Piercing Incendiary/Pointed Bullet/Hard CoreGreen Tip AP/Armor Piercing/Boattail Bullet
2,395 ft/s (730 m/s)3,020 ft/s (920 m/s)
Bullet Level 11
Weapon A11
M1 GarandRemington 700Dragunov
7.62 x 63 M2 AP7.62 x 51 NATO AP7.62 x 54mmR API
RifleSniper RifleSniper Rifle
III
9
A11
RF3
BR7
165/151/154grains10.69/9.78/9.98grams
FMJ/PB/HCFMJ/PB/HC/WCAPI/PB/HC
Full Metal Jacket/Pointed Bullet/Hard CoreFull Metal Jacket/Pointed Bullet/Hard Core/WadcutterArmor Piercing Incendiary/Pointed Bullet/Hard Core
2,880 ft/s (878 m/s)2,690 ft/s (820 m/s)2,820 ft/s (860 m/s)
Bullet Level 12
Weapon A12
Barrett
.50 BMG (12.7 x 99mm)
Rifle
III+
10+
A12
RF3+
BR7+
661 grains42.83 grams
FMJ/Ball
Full Metal Jacket/Ball
3,080 ft/s (940 m/s)
Bullet Level 13
